Componentenlijst pico-ampèremeter

Weerstanden
(alle TH, 5%, 0,25 W, tenzij anders vermeld)
R1, R18, R19, R24 = 1 kΩ
R2, R9 = 1 MΩ, 1%
R3 = 1 GΩ, 1%
R4, R5 = 1 MΩ
R6 = 560 Ω
R7 = 50 kΩ, trimmer (*)
R8 = 10 kΩ
R10 = 1,5 MΩ, 1%
R11 = 120 kΩ, 1%
R12 = 100 Ω, 1%
R13 = 10 kΩ, 1%
R14, R15, R23, R28 = 100 kΩ, 1%
R16 = 27 kΩ
R17 = 4,7 kΩ
R20, R22 = 33 kΩ
R21 = 2 kΩ, trimmer (*)
R24 = 1 kΩ
R25 = 0 Ω
R26 = 10 MΩ
R27 = 22 kΩ, trimmer (*)
R29 = 470 Ω
R30, R31 = 100 Ω
(*) Vishay T93XA-serie, meerslagen-cermet

Condensatoren
C1 = 100 pF, SMD 1206, folie of NP0
C2 = 10 µF, SMD 1206, X7R
C4, C6…C11 = 100 nF, SMD 1206, X7R
C2 = 10 µF, SMD 1206, X7R

Halfgeleiders
D1 = BAV199, SMD (optie)
D2, D3 = 1N4148, TH-type
IC1, IC2 = LMC6482, DIL
IC3 = DG412DJN, DIL
IC4 = ADS1113, adapter-print SMD naar DIL
IC5 = DAC8830, adapter-print SMD naar DIL
IC6 = TL431C, TO-92
Q1, Q2 = 2N7000, N-kanaal-MOSFET

Modules
ESP32 = NodeMCU ESP32 Wi-Fi en Bluetooth
(bijv. Reichelt, bestelnummer DEBO JT ESP32)
OLED = 0,96″ OLED SSD1306-display I²C 128 × 64
(bijv. AZ-Delivery)

Diversen
JP1…JP6, JP13 = header 1 × 1 pin, female, 90°
JP12 = header 1 × 4 pin, female, 90°
JP7 = header 1 × 2 pin, female, 90°
JP8, JP9 = header 1 × 15 pin, female, 90°
JP10, JP11 = header 1 × 3 pin, female, 90°
K1, K2 = COTO 9011-05-11, relais

Componentenlijst voedingsdeel

Weerstanden
(alle TH, 1%, 0,25 W, tenzij anders vermeld)
R1, R2 = 33 Ω, 5%
R3 = 470 Ω
R4, R5 = 2,2 kΩ
R6 = 1,2 kΩ
R7 = 68 kΩ
R8 = 6,8 kΩ

Condensatoren
C1 = 1 µF, 50 V, X7R
C2, C3 = 100 µF, 25 V, d = 10 mm
C4, C5 = 100 nF, SMD 1206

Halfgeleiders
D1, D2 = BAT42, TH-type
IC1 = LM337, TO-92
IC2 = LM317, TO-92

Diversen
M1 = MT3608, step-up DC/DC-converter
JP1 = header 1 × 1 pin, male, 90°
JP2 = header 2 × 2 pin, male, 90°
JP3, JP4 = header 1 × 3 pin, male, 90°
